Dell 480GB SATA RI Hot-Plug SSD Drive 345-BDZB
The Dell SSD Drive with 480 GB, part number 345-BDZB, is a 2.5-inch SATA 6 Gb/s physical unit with a Read Intensive (RI) profile. The listed mounting is hot-plug, with a hybrid carrier for a 3.5-inch bay. This distinction between the SSD size and the mounting is important for selecting the correct assembly.
It is an option for replacement or expansion in Dell PowerEdge servers that support this code. Before purchasing, check the full server model, the bay, the backplane, and the controller. Physical fit and the interface, on their own, do not guarantee compatibility.
Dell SSD Drive Specifications
| Feature | Specification |
|---|---|
| Manufacturer | Dell |
| Part number / SKU | 345-BDZB |
| Listed EAN / GTIN | 5397184688076 |
| Rated capacity | 480 GB |
| Interface | SATA 6 Gb/s |
| Usage profile | Read Intensive (RI) |
| Physical SSD format | 2.5 inches |
| Mounting | Hot-plug with hybrid carrier for a 3.5-inch bay |
| Listed registered weight | 1.0 kg |
| Listed registered dimensions | 10 × 17 × 3 cm, length × width × height; do not necessarily represent the dimensions of the SSD alone |
| Condition | New |
| Warranty listed in the registration | 1 year Dell; confirm the conditions in the proposal |
Applications and selection criteria
The Read Intensive profile is aimed at workloads with a predominance of reading. Suitability for the operating system, applications, or repositories must consider the write volume, the required capacity, and the performance requirements of the environment. Do not assume that the RI rating is appropriate for every enterprise workload.
The unit can be part of a storage upgrade on a supported platform. Final performance depends on the controller, the volume configuration, and the workload, not just the use of an SSD. RAID does not replace data backups.
Compatibility and package contents
- Confirm the approval of 345-BDZB for the full server model.
- Validate the hybrid carrier and the 3.5-inch bay of the platform.
- Check the interface, backplane, RAID controller, and firmware version.
- Check the application's endurance and write requirements in the model documentation.
- Confirm the included items, availability, delivery, and warranty in the quote.
Consult the manuals and the platform matrix on the official Dell support portal. The presence of a SATA port or an LFF bay does not guarantee, on its own, the compatibility of this code.
Frequently Asked Questions
Is the SSD 2.5 or 3.5 inches?
The physical unit is 2.5 inches. The listed mounting uses a hybrid carrier for installation in a compatible 3.5-inch bay.
What is the difference between RI and capacity?
480 GB identifies the rated capacity. Read Intensive identifies the usage profile of the unit. The selection must consider both and the application's write requirements.
Does hot-plug guarantee replacement without downtime?
Not on its own. The operation depends on the platform's support, the state of the volume, and the manufacturer's procedures.
Does the purchase include installation or configuration?
I.T. Computers sells equipment and components; it does not perform installation, configuration, or monitoring as its own services. Manufacturer services only when expressly included in the contracted offer.
Quote and ordering information
Provide the part number 345-BDZB, the quantity, and the full server model. Also check our collection of enterprise servers for infrastructure purchases. The final terms of supply must be stated in the commercial proposal.
