Quais tipos de Transceivers e Módulos SFP/SFP+ estão disponíveis nesta coleção?

A coleção reúne módulos SFP, SFP+, SFP28, QSFP+ e QSFP28 das marcas HPE Aruba, Dell e TP-Link, com opções de fibra multimodo, fibra monomodo e cobre. As velocidades descritas vão de 1G a 100G, conforme o tipo de módulo.

Como escolher entre um transceiver de fibra multimodo, monomodo ou cobre?

A escolha depende do tipo de cabeamento e da distância da conexão. A descrição indica fibra multimodo para distâncias curtas, fibra monomodo para longas distâncias e módulos de cobre para conexões por cabo Ethernet; confira o padrão e o alcance de cada tipo antes de selecionar.

Os módulos desta coleção são compatíveis com switches HPE Aruba, Dell e TP-Link?

A coleção inclui transceivers originais HPE Aruba, Dell e TP-Link, com compatibilidade indicada para linhas como Aruba CX, Instant On e ProCurve; Dell PowerSwitch, S-Series e N-Series; e TP-Link Omada, JetStream e TL-SG. Verifique o fabricante e o modelo do equipamento para escolher o módulo correspondente.

O que é monitoramento DDM nos Transceivers e Módulos SFP/SFP+?

DDM (Digital Diagnostics Monitoring) permite acompanhar em tempo real dados como temperatura do módulo, voltagem, corrente de bias e potência óptica de transmissão e recepção. A descrição também aponta seu uso no troubleshooting de conectividade e na manutenção preventiva.

Os transceivers podem ser instalados ou removidos sem desligar o equipamento?

A coleção descreve os módulos como hot-swappable, permitindo instalação e remoção sem desligar o equipamento. Isso possibilita realizar manutenção e upgrades sem downtime, conforme as informações apresentadas na descrição.

Transceivers and SFP/SFP+ Modules | HPE Aruba, Dell and TP-Link

Transceivers and SFP/SFP+ Optical Modules - High-Speed Enterprise Connectivity

Discover the complete line of SFP, SFP+, and QSFP transceivers and optical modules from HPE Aruba, Dell, and TP-Link for enterprise switches and network equipment. With fiber-optic and copper technology, our modules offer 1G to 100G connectivity for uplinks, long-distance connections, and network infrastructure expansion.

Why Choose Original Transceivers?

Certified Compatibility - Modules tested and certified by the manufacturers (HPE, Dell, TP-Link), ensuring full compatibility with switches and network equipment
Manufacturer Warranty - All transceivers include a manufacturer warranty with specialized technical support and replacement in case of failure
Quality and Reliability - High-quality optical components with low error rates, extended operating temperature, and superior MTBF
Digital Monitoring - Integrated DDM (Digital Diagnostics Monitoring) to monitor temperature, voltage, current, and TX/RX power in real time
Hot-Swappable - Installation and removal without shutting down the equipment, allowing maintenance and upgrades without downtime
Low Power Consumption - Efficient design that reduces power consumption and heat generation in switches and equipment

Available Transceiver Types

SFP 1000Base-SX (MMF) - 1 Gigabit SFP modules for multimode fiber (MMF) with LC connectors. Range up to 550 meters on OM2/OM3 fiber. Ideal for short connections within data centers, between switches in the same rack, or within the same building. Compatible with 850nm fiber.

SFP 1000Base-LX (SMF) - 1 Gigabit SFP modules for single-mode fiber (SMF) with LC connectors. Range up to 10 km on OS2 fiber. Ideal for long-distance connections between buildings, campuses, and branch offices. Compatible with 1310nm fiber.

SFP 1000Base-T (Copper) - 1 Gigabit SFP modules for Cat5e/Cat6 copper cable with RJ45 connector. Range up to 100 meters. Ideal for connecting switches with SFP ports to equipment with standard Ethernet ports without the need for fiber.

SFP+ 10GBase-SR (MMF) - 10 Gigabit SFP+ modules for multimode fiber with LC connectors. Range up to 300 meters on OM3/OM4 fiber. Ideal for 10G uplinks within data centers, connections between ToR switches, and aggregation. Compatible with 850nm fiber.

SFP+ 10GBase-LR (SMF) - 10 Gigabit SFP+ modules for single-mode fiber with LC connectors. Range up to 10 km on OS2 fiber. Ideal for long-distance 10G uplinks between data centers, campuses, and remote sites. Compatible with 1310nm fiber.

SFP+ 10GBase-T (Copper) - 10 Gigabit SFP+ modules for Cat6a/Cat7 copper cable with RJ45 connector. Range up to 30-100 meters. Ideal for connecting servers with 10GBase-T NICs directly to switches with SFP+ ports.

SFP28 25GBase-SR (MMF) - 25 Gigabit SFP28 modules for multimode fiber. Range up to 100 meters on OM4 fiber. Ideal for 25G connectivity for modern servers and high-speed uplinks.

QSFP+ 40GBase-SR4 (MMF) - 40 Gigabit QSFP+ modules for multimode fiber with MPO/MTP connectors. Range up to 150 meters. Ideal for 40G uplinks between spine-leaf switches.

QSFP28 100GBase-SR4 (MMF) - 100 Gigabit QSFP28 modules for multimode fiber with MPO/MTP connectors. Range up to 100 meters. Ideal for high-speed data center backbones.

Network Applications

Transceivers are essential for uplinks between switches (ToR to aggregation), long-distance connections (between buildings, campuses, and branch offices), storage connectivity (SAN, NAS, NVMe-oF), data center backbones (spine-leaf), server aggregation (10G/25G), WAN connections (between sites), port expansion (converting SFP ports to Ethernet), and speed migration (upgrading from 1G to 10G/25G).

Manufacturer Compatibility

HPE Aruba: Compatible with Aruba CX, Instant On, and ProCurve switches. Models J4858D (1G SX), J4859D (1G LX), R9D16A (1G SX Instant On), R9D17A (1G-T Instant On), R9D18A (10G SR Instant On).

Dell: Compatible with Dell PowerSwitch, Networking S-Series, and N-Series switches. Original Dell modules for S4112F, S4128F, S5224F, S5248F, and other models.

TP-Link: Compatible with TP-Link Omada, JetStream, and TL-SG series switches. Models TL-SM5110-SR (10G SR), TL-SM311 series for Gigabit and 10 Gigabit connectivity.

Fiber Optics: Multimode vs. Single-Mode

Multimode (MMF): Fiber with a larger core (50/62.5 µm) for short distances (up to 550m). More economical, ideal for data centers. Types: OM1, OM2, OM3, OM4, OM5.

Single-Mode (SMF): Fiber with a smaller core (9 µm) for long distances (up to 10-80 km). More expensive, ideal for WAN and campuses. Type: OS2.

DDM Monitoring

Digital Diagnostics Monitoring (DDM) allows real-time monitoring of module temperature, supply voltage, bias current, TX (transmission) optical power, and RX (reception) optical power. Essential for troubleshooting connectivity issues and preventive maintenance.

Original HPE Aruba, Dell, and TP-Link transceivers with manufacturer warranty, integrated DDM, and delivery throughout Brazil. Invest in reliable connectivity and expand your network infrastructure with enterprise-quality optical modules.
